Specialty size

12”

Schedule 40 90x48

Having the equipment to make specialty items is not all there is to fabrication. It takes a specially trained and motivated team to make beauties like this. Thank you to Javier (left) and Adrian (right) for your work and support!


Design.

It all begins with an idea.

We are always happy to assist in designing custom products to fulfill your requirements.




Fabricate.

Where concept becomes reality.

Hard work, precise calculations, and experience some together to get the job Done.


Admire.

We take pride in our work; no short-cuts, no job done half way.

Common Terminology



Degree -

When talking about a bend, the degree refers to the degree of the curve on the bend. There is a standard tolerance of ± 2°

Arc Length-

The length of the curved portion in a bend. This measurement is not a straight line but instead follows the the center line of the pipe.

Radius -

the distance from the center of the pipe bend, to the center of the circle it would form if assembled to make 360­°

Tangent-

The straight portion of a bend remaining on either side of the arc lengths/curve

Chord length-

In regards to a bend, the chord length refers to the measurement of a straight line from one center-line endpoint to the other.

Nominal Size-

The approximate size of the pipe by which it is commonly referred to but differs from the actual dimension. In regards to pipe, this would be the nominal size of its outer diameter.
